Centrifugal Industrial Electrical Horizontal Slurry Pump Heavy Duty Sludge Pump Types
| Model | P028B126P-IPSV2 |
| Screen Size | 2.8 inch |
| Number of Pixel | 240RGB(H)x320(V) |
| Display area | 43.2(H)x57.6(V)mm |
| Pixel pitch | 0.18(H)x0.18(V)mm |
| Pins | 24 pins |
| Outline Dimension | 50.00x69.20x2.30mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 262K |
| Luminance(cd/m2) | 900 nit |
| Contrast Ratio | 1200:01:00 |
| Interface | MCU 8bit |
| Back-light | LED Side-light type |
| Drive IC | ST7789P3-G6 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
Specification Data
| Discharge Size:20mm~350mm | NPSH:0m~3m |
| Inlet Size:32mm~400mm | Allowed Max Particle Size:20 mm |
| Capacity:4 ~ 3000 m³/h | Seal Type:step-down dynamic seal |
| Head:10 ~ 130 m | Pump Weight:up to 3000kg |
| Maximal Efficiency:70% | RPM:1450 r/min |
Application
| Automobile pickling | Non-ferrous metal metallurgy | Caustic soda | Pesticide |
| Electronics | Papermaking | Rare-earth separation | Pharmaceutical |
| Pulp production | Sulfuric acid industry | Environmental protection |
Main Feature
1) Bearing assembly- large diameter shaft with short overhang contributes to long bearing life.
2) Liners – easily replaceable liners are bolted, not glued to the casing for positive maintenance.
3) Casing – Casing halves of cast or ductile iron provide high operating pressure capabilities.
4) Impeller – front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
Structure
Materials Choose
| IMPELLERS | CASING | COLUMN | DISCHARGE | SEALS |
Standard | High Chrome Alloy Rubber | High Chrome Alloy Rubber | Mild Steel | Mild Steel | Natural Rubber |
Options | Butyl | Neoprene | Neoprene | Neoprene | Nordel |
