Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller
  • Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller
  • Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller
Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller

Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller

Place of Origin Guangzhou China
Brand Name horizontal-slurrypump.com
Certification CE ISO CCC UKAS,ROHS
Model Number OEM
Document Product Brochure PDF
Product Details
Materail:
Coated Matel
Contactor:
Fuji Brand
Copper Thick:
1 Mm
Compressor:
With Oil Heater
Display:
LCD Finger Touch
Control:
Wifi Function Support
Reted Heating Capacity:
100KW
Power Supply:
380V/ 50Hz
Power Input:
25KW
Noise:
68Db(a)
Highlight:

swimming pool air source heat pump

Payment & Shipping Terms
Minimum Order Quantity
5 PCS
Price
Negotiation
Packaging Details
Plywooden case
Delivery Time
15 days
Payment Terms
T/T, L/C WESTERN UNION
Supply Ability
800/MONTH
Product Description

Swimming Pool Heat Pump Heating 100kw High COP water chiller



Technology Specification





Swimming pool heat pump



1. Swimming pool heater pump can be installed in many environments, including a constant temperature

swimming pool, sauna constant hot water system, villa, or to supply hot water at home.


2.Pure titanium pool heat exchanger, anti-corrosion and durable.


3. Durable coating in white or metal-grey.


4. Auto-defrost function available.


5. Easy installation, connect the inlet /outlet water pipe and then enjoy it.





Swimming pool heat pump parameter tables





MODEL Unit MDY10D
Rated heating capacity KW 3.5
Average heating input power KW 0.8
Rated heating input current A 6
Max outlet water temp ℃ 35
COP 　 3.8
Power V/Hz 220V/50
Noise Db(a) 48
Dimension W*D*H mm 1140×360×538
Packing size W*D*H mm 1180*380*680
Unit weight KG 70
Refrigerant 　 R417A/R410
Working air temp range ℃ (-20℃)—45℃
compressor Type 　 Panasonic
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 1200L/h
Water pressure down Kpa 30
Pipe size(water connection) DN 50
MODEL Unit MDY15D
Rated heating capacity KW 5.5
Average heating input power KW 1.25
Rated heating input current A 6
Max outlet water temp ℃ 35
COP 　 3.8
Power V/Hz 220V/50
Noise Db(a) 48
Dimension W*D*H mm 1140×360×539
Packing size W*D*H mm 1180*380*680
Unit weight KG 70
Refrigerant 　 R417A/R410
Working air temp range ℃ (-20℃)—45℃
compressor Type 　 Panasonic
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 1800L/h
Water pressure down Kpa 30
Pipe size(water connection) DN 50
MODEL Unit MDY20D
Rated heating capacity KW 9
Average heating input power KW 1.84
Rated heating input current A 7
Max outlet water temp ℃ 35
COP 　 3.8
Power V/Hz 220V/50
Noise Db(a) 50
Dimension W*D*H mm 1140×360×540
Packing size W*D*H mm 1180*380*680
Unit weight KG 75
Refrigerant 　 R417A/R410
Working air temp range ℃ (-20℃)—45℃
compressor Type 　 Panasonic
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 3500L/h
Water pressure down Kpa 30
Pipe size(water connection) DN 50
MODEL Unit MDY30D
Rated heating capacity KW 14
Average heating input power KW 3
Rated heating input current A 13/6
Max outlet water temp ℃ 35
COP 　 4
Power V/Hz 220V/380/50
Noise Db(a) 55
Dimension W*D*H mm 1120*490*790mm
Packing size W*D*H mm 1200*520*870mm
Unit weight KG 110
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20℃)—45℃
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 5500L/h
Water pressure down Kpa 40
Pipe size(water connection) DN 50
MODEL Unit MDY40D
Rated heating capacity KW 16
Average heating input power KW 4
Rated heating input current A 18/9
Max outlet water temp ℃ 35
COP 　 4.2
Power V/Hz 380V/50
Noise Db(a) 55
Dimension W*D*H mm 1120*490*1270
Packing size W*D*H mm 1200*520*1440
Unit weight KG 160
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20℃)—45℃
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 6500L/h
Water pressure down Kpa 45
Pipe size(water connection) DN 50
MODEL Unit MDY50D
Rated heating capacity KW 19
Average heating input power KW 4.4
Rated heating input current A 9
Max outlet water temp C 35
COP 　 4.2
Power V/Hz 380V/50
Noise Db(a) 55
Dimension W*D*H mm 1120*490*1270
Packing size W*D*H mm 1200*520*1350
Unit weight KG 160
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20C)—45C
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 7500L/h
Water pressure down Kpa 45
Pipe size(water connection) DN 50
MODEL Unit MDY60D
Rated heating capacity KW 26
Average heating input power KW 6
Rated heating input current A 12
Max outlet water temp ℃ 35
COP 　 4.2
Power V/Hz 380/50
Noise Db(a) 60
Dimension W*D*H mm 1120*490*1270
Packing size W*D*H mm 1200*520*1350
Unit weight KG 210
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20℃)—45℃
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 9000L/h
Water pressure down Kpa 48
Pipe size(water connection) DN 50
MODEL Unit MDY100D
Rated heating capacity KW 42
Average heating input power KW 9.2
Rated heating input current A 18
Max outlet water temp C 35
COP 　 4.2
Power V/Hz 380V/50
Noise Db(a) 60
Dimension W*D*H mm 1450×760×1060
Packing size W*D*H mm 1520*760*1190mm
Unit weight KG 289
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20C)—45C
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 15000L/h
Water pressure down Kpa 54
Pipe size(water connection) DN 63
MODEL Unit MDY150D
Rated heating capacity KW 50
Rated Cooling capacity KW 37
Average input power KW 11
Rated input current A 24
Max outlet water temp C 38
COP 　 4.5
Power V/Hz 380V/50
Noise Db(a) 60
Dimension W*D*H mm 1450×760×1060
Packing size W*D*H mm 1520*760*1190mm
Unit weight KG 320
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20C)—45C
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 18000L/h
Water pressure down Kpa 54
Pipe size(water connection) DN 63
MODEL Unit MDY200D
Rated heating capacity KW 84
Average heating input power KW 19
Rated heating input current A 35
Max outlet water temp ℃ 35
COP 　 4.5
Power V/Hz 380V/50
Noise Db(a) 65
Dimension W*D*H mm 1990*980*2080
Packing size W*D*H mm 2080×1150×2130
Unit weight KG 650
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20℃)—45℃
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 28000L/h
Water pressure down Kpa 60
Pipe size(water connection) DN 63
MODEL Unit MDY300D
Rated heating capacity KW 100
Average heating input power KW 25
Rated heating input current A 45
Max outlet water temp ℃ 35
COP 　 4.5
Power V/Hz 380V/50
Noise Db(a) 68
Dimension W*D*H mm 1990*980*2080
Packing size W*D*H mm 2080×1150×2130
Unit weight KG 650
Refrigerant 　 R417A/R407C/R410A
Working air temp range 　 (-20℃)—45℃
compressor Type 　 Copeland
Air source heat exchanger Type 　 Finned heat exchange
Fan Type 　 axial flow fan
Hot water side heat exchange Type 　 Titanium heat exchanger
Water flow L/H 45000L/h
Water pressure down Kpa 60
Pipe size(water connection) DN 63







Specifications

Swimming pool heat pump heating:


1. High efficiency & energy saving


2. Safe & Comfort


3. Convenient & widely to use



4. Swimming Pool Heat Pump heating:

  • Swimming pool heat pump can save you up to 80% in operating cost whether you just want to extend your swimming season or swim all year round in a warm comfortable pool.
  •
  • With special designed heat exchangers, Swimming pool heat pump can give you the perfect water temperature without a big increase in your power bill, our swimming pool heat pump is a perfect selection to your in-ground swimming pool or sea.
  •
  • The product can be widely installed at any kind of places, such as constant temperature swimming pools, sauna constant hot water system and supplying domestic hot water to home.

Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller 0



Coated Matel Swimming Pool Heat Pump / 100kw High COP Water Chiller 1



Our Services



1. After installation, our company will be responsible for problems caused by quality of production or raw material except the damageable spare parts of heat pump caused by incorrect man-made operation during the guarantee period.



2. Intelligent Controlling service system will be avoid the long distance of the after sale problem. Wherever are you, our engineer can be controlled your equipment, when some questions occur on the equipment. Just tell us what number will be shown on the screen, then the engineer will be solve the problem.



3. We accept OEM, ODM and customization.



4. 24*7 after sales service. You will get satisfied service.



5. We have More than 17years production and sales experience; Professional sales team.



  • FAQ
  • What is your advantage, comparing with other water heaters?
  •
    • A: Avoiding electric water heater leakage, dry, high power consumption.

    • B: Avoiding the drawbacks of gas water heater, such as producing harmful gases,
    • Fits and starts etc.
    •
    • C: Energy efficient, safety and environmental protection, all-weather operation, easy to use.



  • What details do you need?

A: Pool: Length, width, depth.



B: Ambient temperature.



C: Water input and output temperature.



  • Will it be too trouble to use air water heater?

Easy to use, once set, always have hot/cool water



  • How long is the life of air water heater

Life span is 12-15 years



  • .How many years guarantee?

1 years
